non-linear receiver

non-linear receiver
  1. нелинейная нагрузка



нелинейная нагрузка
Нагрузка, в которой ток и напряжение связаны между собой нелинейным законом.

EN

non-linear load
load where the parameter Z (load impedance) is no longer a constant but is a variable dependent on other parameters, such as voltage or time
[IEC 62310-3, ed. 1.0 (2008-06)]

FR

charge non linéaire
charge où le paramètre Z (impédance de charge) n’est plus une constante mais une variable dépendant d’autres paramètres, comme la tension ou le temps
[IEC 62310-3, ed. 1.0 (2008-06)]

На рисунке показаны осциллограммы напряжения и тока, протекающего через импульсный источник питания компьютера. Видно, что при синусоидальном питающем напряжении форма кривой потребляемого тока существенно отличается от синусоидальной (т. е. зависимость тока от напряжения является нелинейной).
Компьютер - типичный пример нелинейной нагрузки.

Тематики

  • электроснабжение в целом
  • электротехника, основные понятия

Классификация

>>>

EN

  • distorting load
  • non-linear load
  • non-linear receiver

FR

  • charge non linéaire


Англо-русский словарь нормативно-технической терминологии. . 2015.
